Cisco D9854 Installation And Configuration Guide

Chapter 4 Front Panel Operation
90
Menu Item
Description
Parameters
Reset Credentials
If for some reason, you cannot access
the decoder (due to a forgotten
password, corrupted data, and so on),
the recovery procedure for the
decoder is as follows:
Using the keypad, choose this field on
the front panel menu. A default login
username and randomly generated
password will be displayed on the
front panel display for approximately
30 seconds. The new account will
have Admin privileges. We
recommend that this account be
replaced by a login
username/password chosen by the
administrator. To change the
username and password, you must be
an Admin user. Refer to Setting
Admin User Privileges via a
Telnet/SSH Connection (on page 38).
Note: After this recovery procedure,
all existing user accounts will be lost.
–
Password
Complexity
Sets the password complexity for all
users. The complexity level changes
will only affect the new user accounts
and password changes. It will not
affect existing accounts.
No Checking, Minimal Checking, or
Full Complexity Checking
For more information, see the
Password Complexity table below.
SNTP Server
Sets the NTP server address. If the
NTP server address is not set (0.0.0.0),
the IRD will not attempt to connect to
the server.
12 digits in length (###.###.###.###)
SNTP Enable
Periodically request NTP timestamps
from the NTP server and to
synchronize its system (i.e., non-DVB
related) time with the NTP server.
Yes or No
Passw ord Complex ity
Password Complexity
Description
No Checking
There are no restrictions on passwords.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
