Cisco D9854 Installation And Configuration Guide

Chapter 4 Front Panel Operation
104
VBI
WSS
Menu Item
Description
Parameters
WSS Mode
Selects the Wide Screen Signaling
output mode. It is used to select
how the receiver affects PAL WSS
when it is present in the VBI line 23.
Auto:Create - Creates WSS to
output the correct aspect ratio,
when performing aspect ratio
conversion.
Auto:Modify - If WSS is
present in the input stream, it
is modified to output the
correct aspect ratio when
performing aspect ratio
conversion. If WSS is not
present in the input, no WSS
will be present in the output.
Suppress - Removes WSS
output.
Passthrough - Passes WSS
unmodified as received by the
receiver.
The default is Passthrough.
WSS Stat
This indicates the current output
value of PAL WSS in VBI line 23.
4:3 F/F, 16:9 L/B CEN, 16:9
L/B TOP, >16:9 L/B, 14:9 L/B
CEN, 14:9 L/B TOP, 14:9 F/F
CEN, 16:9 F/F, or
UNDEFINED
Note: F/F is full format, and
L/B is letter box.
VITC
This is not supported in the current release.
VITS
Menu Item
Description
Parameters
VITS PAL Line 17,
18, 330, 331
Select whether to enable or disable
Vertical Interval Test Signal on PAL
Lines 17, 18, 330, or 331.
Enable or Disable
SDI
Note: This feature is for D9854-I and D9854 with SDI only.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
