Cisco D9854 Installation And Configuration Guide

Chapter 4 Front Panel Operation
110
Menu Item
Description
Parameters
Idx
Select the component record to
edit.
1-64 (up to 32 records for each
CAM)
PE
Set the Program Entry the
component is located.
1 to 16
Mode
Select whether to choose the
component by PID or by stream
type.
PID or STREAM
PID
If decrypting by PID, set the PID
number.
0 to 8192
Stream
If decrypting by stream type and
set the stream type.
AUD (audio), VID (video),
SUBT (subtitles), TTX (teletext),
USER
Note: Select USER to manually
enter a stream type in the Type
parameter.
Type
If decrypting by stream type and
the stream category is USER, set
the stream type value.
0 to 255
Inst
If decrypting by stream type, set
the instance of the current stream
type.
1 to 64
Query
Set to Enable to query the CAM
prior to decryption to ensure that
the program can be decrypted.
Enabled or Disabled (default)
Auto Reset
Set to Enable to automatically reset
the card.
Enable or Disabled (default)
List Mgmt
Select whether the Common
Interface List Management should
add or delete individual programs
or update all the programs when
the list changes.
AddDel or Update All
Note: Updating all the
programs will cause a
temporary loss of service for all
the programs when another is
being modified.
TS_ON_ID
Set to Enable if you want to restrict
the incoming transport stream.
If the incoming stream does not
match the transport stream and
original network ID specified
(TS_ID and ON_ID), the program
will not be decrypted.
Enable or Disable (default)
TS_ID
Specify the Transport ID.
0 to 65535

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
