Cisco D9854 Installation And Configuration Guide

Setup Menu
133
7 Go to Setup: Outputs, TS Out: ASI, and set the Output Mode to Full DPM
Control. Also, if necessary set the Descramble Mode according to whether the
program is to be Scrambled or Descrambled for downstream
viewing/monitoring.
8 On the same menu, set the following parameters:
Parameter
Description
Map Mode
Svc ID & PID
Duplic Mode
Pkt Copy
Unref
Drop
PSI Options
Ctl By Table
PSI Rate
Any
Svc ID
Any
9 Set the table parameters as follows:
Parameter
Description
PAT
Regen
CAT
Regen
PMT
Regen
TSDT
Drop
NIT
Regen or Drop
NITO
Drop
SDT
Regen
SDTO
Drop
BAT
Drop
EIT
Drop
TDT
Pass
RST
Pass
TOT
Pass
DIT
Pass
SIT
Pass
ECM
Drop
EMM
Drop
DRT
Drop
CDT
Drop

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
