Cisco D9854 Installation And Configuration Guide

Setting up Input Information
177
Parameter
Description
Input Rate (Mbps)
Displays the bit rate of the input transport stream, in Mbps.
Acquisition State
Displays Full if the SI and PSI tables have all been found.
Otherwise, it will display Degraded if there are missing tables
or None if no SI or PSI tables have been found.
Link Status
Displays the link status of the active data port (Up or Down).
Port In Use
Displays the current input port in use (Data1 or Data2).
Transport Stream
The Transport ID (in the range from 1 to 65535).
Locked Data1/Data2
Source
When locked, this displays the source/host IP address of the
originator. If the signal is not locked, it will display N/A.
Switchover Reason
Displays a description of the reason for the last redundancy
switchover (Setup, EthLinkStatus, TS Status, ProgStatus, or
None).
Switchover Date/Time
Displays the last date and time for the last redundancy
switchover.
PCR Lock
Indicates whether the system is locked to the required PCR PID
(Yes or No).
De-jitter Latency (msec)
Displays the overall transport stream buffer latency, in
milliseconds.
FEC Bitrate (Mbps)
Displays the input stream bit rate reported by the FEC decoder.
FEC CEC
Indicates the current Corrected Error Count for the received
stream.
FEC PER
Indicates the current Packet Error Rate of the received stream.

Cisco D9854 Specifications

General

Model	D9854
Category	Receiver
Output	ASI, IP
Decoding	MPEG-2
Conditional Access	BISS
Receiver Type	Professional IRD
解密	DVB-CSA, BISS, AES
Input Frequency Range	950 MHz to 2150 MHz
Modulation Formats	QPSK, 8PSK
Symbol Rate	1 to 45 Msps
Power Supply	100-240 VAC, 50/60 Hz
Power Consumption	40W (typical)
Operating Temperature	0°C
