5-14
Cisco D9865 Satellite Receiver Software Version 2.20 Installation and Configuration Guide
OL-31085-01
Chapter 5 Setup and Monitoring via Web GUI
Setting Up Dish Pointing
Step 4 From the Service List Mode drop-down list, choose which tables to use to obtain tuning and channel
lists.
Choose Rigorous if all the default settings must be present in the received signal.
Choose Degraded if only the table parameters present in the received signal will be used to install the
receiver. The default is Rigorous.
Step 5 The Service List Contributors area allows you to set up custom properties. The following table shows
some possible configurations for the allowed service lists and the different frequency tuning settings.
Note You cannot change the Bouquet Association Table value. It is not supported in the current
release.
Step 6 Click OK.
Step 7 From the CA Mode drop-down list, choose the Conditional Access mode that determines which
programs can be viewed via the receiver. You can select Std (preferred) or Open.
Caution In Open mode, the receiver ignores inconsistent scrambling descriptions within the signal.
Operating in this mode may cause the decoder not to respond to certain advanced uplink
controlled features, such as service replacement.
Step 8 In the Network ID enter the network ID, obtained from your service provider.
Step 9 The SI Receive Status area displays all the current SI Receive settings. It also displays the source of last
tuning, the last Preset Number activated, and the current settings of the allowed services (BAT, NIT,
SDT, PAT).
Step 10 Click Apply.
Allowed Service Lists Custom
Bouquet Association Table (BAT) (not supported) N
Network Information Table (NIT) N
Service Description Table (SDT) N
Program Association Table (PAT) Y
Frequency Tuning mode User Cfg
