Cisco D9865 Installation And Configuration Guide

5-38
Cisco D9865 Satellite Receiver Software Version 2.20 Installation and Configuration Guide
OL-31085-01
Chapter 5 Setup and Monitoring via Web GUI
Setting Up IP Information
c. In the Gateway Address field, enter the network gateway address used to expose the receiver to a
WAN.
d. Click Add.
e. To remove an address entry, click the entry radio button and click Delete.
Step 5 The Multicast Filtering Addresses section lists the multicast destination IP addresses. To add a new
address, click Add. The following is displayed:
a. In the Multicast Filter Address field, enter the multicast filter address and click Add.
b. To remove an address entry, click the entry radio button and click Delete.
Step 6 Click Apply.
Setting Up SNMP and Trap Destinations
Proceed as follows to configure the SNMP settings:
Step 1 From the user interface of the D9865, choose System Settings > System > IP Settings > SNMP. The
SNMP page is displayed.
Step 2 In the Read Community String and the Write Community String fields, enter public or a custom
string. The SNMP Community Read/Write is used when communicating with a device within an SNMP
environment. These commands allow you to set the password to read and write data to a device to display
