4-50
Cisco D9865 Satellite Receiver Software Version 2.20 Installation and Configuration Guide
OL-31085-01
Chapter 4 Setup and Monitoring via On-Screen Display
Setup Menu
Step 3 Click the green button (Save) to save the changes.
Editing/Deleting Trap Destinations
Proceed as follows to edit/delete trap destinations.
Step 1 In the Trap Destination Setup screen, select the trap destination address you want to edit or delete and
press OK.
Step 2 Press the blue button (Edit) to edit the address. Press the red button (Delete) to remove the address from
the Trap Destination list.
Step 3 If you pressed the blue button, you can edit the Trap Destination Address and Community String and
press the green button (Save) to save your changes.
Step 4 If you pressed the red button (Delete), a warning message appears. Press OK to delete the selected trap
destination entry. Otherwise, press Exit.
Configuring Noise Cutoffs
The Noise Cutoffs screen allows you to set the muting thresholds for both audio and video in the event
of a noisy signal.
Proceed as follows to configure the noise cutoffs:
Step 1 From the Advanced Setup screen, select Noise Cutoffs and press OK. A message appears confirming
that you want to edit the noise cutoffs.
Step 2 Select Ye s to edit. Otherwise, select No.
Step 3 The following table describes each of the options:
