Cisco D9865 Satellite Receiver Software Version 2.20 Installation and Configuration Guide
OL-31085-01
Appendix A Technical Specifications
Audio Outputs
Audio Outputs
Analog Audio Output
Digital Audio S/PDIF Output
VBI
Power
AC Power Connector
Parameter Specification
Number of Channels 1 stereo pair/2 mono channels
Connector Type RCA
Output Level Unbalanced, 2 V rms ± 10% at 0 dBFS
Audio Decompression MPEG 1 Layer 2, Dolby Digital Plus, HE-AAC
Parameter Specification
Connector Type RCA
Output Impedance 75 +/-20%, from 0.1 MHz to 6.0 MHz
Signal Amplitude 0.5V +/-20% at 75
Parameter Specification
NTSC Lines 10 to 22 fields 1 and 2
PAL Lines 7 to 22 fields 1 and 2
WST, WSS, VPS
Parameter Specification
Voltage Range 100 V to 240 V AC
Line Frequency 50/60 Hz
Power Consumption 35 W max.
LNB Power on satellite input +13 V/+ 18 V @ 350 mA max.
