Cisco D9865 Satellite Receiver Software Version 2.20 Installation and Configuration Guide
OL-31085-01
Chapter 4 Setup and Monitoring via On-Screen Display
Setup Menu
LNB Power Settings
The following table displays the LNB Power settings:
Setting Up the Satellite Dish
The Dish Setup menu provides graphical assistance for dish positioning. This menu can be set to two
modes: User Mode (default) or Installer Mode. The User mode allows you to select from stored Satellite
Numbers, which are stored satellite locations, as stored in the dish motor, but does not provide any dish
control.
Proceed as follows to set up the dish:
Step 1 From the Setup Menu, select Dish Setup and press OK. By default, the Dish Setup screen is displayed
in User mode.
LNB Power Settings NIT Contains Output LNB Voltage
Off Not received Off
HOff
VOff
18-H Not received 18 volts
H 18 volts
V 18 volts
13-V Not received 13 volts
H 13 volts
V 13 volts
H-NIT Not received 18 volts
H 18 volts
V 13 volts
V-NIT Not received 13 volts
H 18 volts
V 13 volts
