Chapter 4 Setup and Monitoring via On-Screen Display
Setup Menu
Note If you enter an invalid frequency setting or a setting that does not correspond to the selection, a pop-up
message such as “Input value out of range" is displayed.
Step 3 Press the green button (Save) to save your settings.
LNB Power
(For more information,
see LNB Power
Settings, page 4-21.)
18-H For H polarization.
13-V For V polarization.
Off Use for external LNB power.
LNB power must be on if DiSEqC is required.
H-NIT Initially applies the horizontal polarization
voltage, and then follows the polarization based on
the NIT.
V-NIT Initially applies the vertical polarization voltage,
and then follows the polarization based on the
NIT.
LO Freq1 Enter number If C-band application, set to 5.15 GHz (default).
If Ku-band single LNB, enter LO Freq. and set LO
Freq 2 and Crossover to 0.0.
If Ku-band dual LNB, enter LO Freq 1, LO Freq 2
and Crossover.
LO Freq2 Enter number Enter if Ku-band dual LNB application. LO Freq 2
> LO Freq 1.
Crossover Enter number Enter if Ku-Band dual LNB application. Used to
determine if LO Freq 1 or LO Freq 2 is used for
tuning.
LO Select
(Sets a 22 kHz tone for
Ku-band dual LNB)
Off Switches 22 kHz tone off.
On Switches 22 kHz tone on.
Auto Sets 22 kHz tone to automatic.
If Downlink Freq < Crossover use LO1. The 22
kHz tone is Off.
If Downlink Freq > Crossover use LO2. The 22
kHz tone is On.
DiSEqC Enable Enables or disables Digital Satellite Equipment
Control, level 1.2. This must be enabled to control
the DiSEqC switch. LNB Power must be on to use
this setting. Refer to
http://www.eutelsat.com/satellites/4_5_5.html for
more information.
Disable
DiSEqC Switch Off Selects a port on the LNB switch (if used).
A to P
Selection Options Description
