Cisco D9865 Installation And Configuration Guide

A-2
Cisco D9865 Satellite Receiver Software Version 2.20 Installation and Configuration Guide
OL-31085-01
Appendix A Technical Specifications
LNB Requirements
Tuner
LNB Requirements
DVB-S and DVB-S2
Parameter Specification
Number of RF Inputs 1
Input Level -25 dBm to -65 dBm per carrier
Frequency Range 950 MHz to 2150 MHz
Symbol Rate Range DVB-S: 1.0 to 45 MS/s
DVB-S2: 1.0 to 31 MS/s
Satellites C-band and Ku-band
Receiver Spectrum Sense Normal and Inverted
Input Impedance 75 
Symbol Rate Stability
1 to 2.99 MS/s 
± 0.125 MHz
3 to 5.99 MS/s 
± 1.00 MHz
6 to 11.99 MS/s 
± 3.00 MHz
12 to 45 MS/s 
± 5.00 MHz
Parameter Specification
LNB Phase Noise Requirement -28 dBc/Hz at F = 100 Hz
-53 dBc/Hz at F = 1 kHz
-76 dBc/Hz at F = 10 kHz
-93 dBc/Hz at F = 100 kHz
-106 dBc/Hz at F = 1 MHz
-117 dBc/Hz at F = 10 MHz
