5-22
Cisco D9865 Satellite Receiver Software Version 2.20 Installation and Configuration Guide
OL-31085-01
Chapter 5 Setup and Monitoring via Web GUI
Configuring the Common Interface (CI) Information
Step 5 The PID Information area displays the PIDs associated with a selected channel.
Configuring the Common Interface (CI) Information
The Common Interface (CI) slot is located behind the door on the front panel. They allow use of a CAM
(Conditional Access Module) Smartcard to decrypt purchased programming.
Note You must be authorized to view the programming available via the Smart Card from your service
provider.
CAMs must be purchased from Cisco. For a list of the supported CAMs, see Common Interface Modules,
page 3-4.
Proceed as follows to configure the CI settings:
Step 1 From the user interface of the D9865, choose Input > Conditional Access. The CI Setup page is
displayed.
Channel Information Description
Conditional Access System Indicates the type of CA used for the received signal.
Authorized Indicates whether the receiver is authorized to receive the signal.
Scrambled Indicates whether the received signal is scrambled.
Encrypted Indicates whether the received signal is encrypted.
