4-41
Cisco D9865 Satellite Receiver Software Version 2.20 Installation and Configuration Guide
OL-31085-01
Chapter 4 Setup and Monitoring via On-Screen Display
Setup Menu
Step 3 Set the Acquisition Mode used to build channel lists from allowed service lists (Basic, Auto, or
Custom). Select Custom to customize the tables used to obtain tuning and channel lists.
Step 4 If the Acquisition Mode was set to Custom, you can set the Tuning Source to indicate whether the
receiver is tuned to the received signal using the NIT or a Preset. The default is NIT.
Step 5 The Service List Mode indicates which tables are used to obtain tuning and channel lists. This only
applies when Acquisition Mode is set to Custom. Select Rigorous if all default settings must be present
in the received signal. Select Degraded and only the table parameters present in the received signal will
be used to install the receiver.
The following table displays the default settings for the allowed service lists and frequency tuning
settings.
Viewing the Network Setup Menu (D9865D only)
Proceed as follows to view the Network Setup screen (D9865D only).
From the Advanced Setup menu, select Network Setup and press OK.
The function for the available sub-menus is as follows:
• IP Setup
–
From this menu, you can configure the receiver for Ethernet operation.
• Unicast IP Setup
–
From this menu, you can configure network destinations for unicast transmission.
• Multicast IP Setup
Allowed Service lists Auto Basic Custom
BATNoNoNo
NIT Yes Yes No
SDT Yes No No
PAT Yes No Yes
Tuning Source NIT NIT Preset
