Chapter 4 Setup and Monitoring via On-Screen Display
Setup Menu
Video Output Restrictions
The following table describes the nature of the Video Outputs given the source video stream and
selections that can be made by the user. The D9865 does not provide video format conversion.
Video formats that require a frame rate change from the original source stream are blocked by a “Video
Format Mismatch” banner and the video output is muted.
Source Video
Format
User Selected
SD Format
User Selected HD
Format Component & HDMI CVBS & TV-Out
SD-NTSC
(60Hz)
Auto or NTSC Auto 1080i 60Hz NTSC
1080i 1080i 60Hz NTSC
720p 720p 30Hz NTSC
PAL (50 Hz) Any Mismatch Mismatch
SD-PAL
(50Hz)
Auto or PAL Auto 1080i 50Hz PAL
1080i 10801 50Hz PAL
720p 720p 25Hz PAL
NTSC Any Mismatch Mismatch
1080i 60Hz Auto or NTSC Auto 1080i 60Hz NTSC
1080i 1080i 60Hz NTSC
720p 720p 30Hz NTSC
PAL Any Mismatch Mismatch
1080i 50Hz Auto or PAL Auto 1080i 50Hz PAL
1080i 1080i 50Hz PAL
720p 720p 25Hz PAL
NTSC Any Mismatch Mismatch
720p 30Hz Auto or NTSC Auto 720p 30Hz NTSC
1080i 1080i 60Hz NTSC
720p 720p 30Hz NTSC
PAL Any Mismatch Mismatch
720p 25Hz Auto or PAL Auto 720p 25Hz PAL
1080i 10801 50Hz PAL
720p 720p 25Hz PAL
NTSC Any Mismatch Mismatch
