Chapter 4 Setup and Monitoring via On-Screen Display
Setup Menu
Setting up Tuning / Preset
The Tuning/Preset menu is used to display and configure the current settings.
Proceed as follows to set up the tuning/preset:
Step 1 From the Setup Menu screen, select Tuning / Preset and press OK.
Step 2 The following table describes each of the available options:
Selection Options Description Default
Modulation Type DVB-S
DVB-S2
Enter the modulation scheme. DVB-S2
Downlink (Freq) Enter number For C-Band:
Downlink Freq = LO Freq -
L-Band Freq.
For Ku-Band:
Downlink Freq = LO Freq +
L-Band Freq.
12.3
Symbol Rate 1.0 to 45.0
1.0 to 31.0
Range for DVB-S in MS/s.
Range for DVB-S2 in MS/s.
30.0
NetId Enter number Obtain the number from your
service provider.
1
