4-16
Cisco D9865 Satellite Receiver Software Version 2.20 Installation and Configuration Guide
OL-31085-01
Chapter 4 Setup and Monitoring via On-Screen Display
Setup Menu
LO Select
(Sets a 22 kHz tone for
Ku-band dual LNB)
On Switches 22 kHz tone on. Off
Off Switches 22 kHz tone off.
Auto Sets 22 kHz tone to automatic.
If Downlink Freq < Crossover,
use LO Freq 1. The 22 kHz tone
is Off.
If Downlink Freq > Crossover,
use LO Freq 2. The 22 kHz tone
is On.
LO Freq 1 Enter number If C-band application, set to 5.15
GHz (default).
If Ku-band single LNB, enter LO
Freq. and set LO Freq 2 and
Crossover to 0.0.
If Ku-band dual LNB, enter LO
Freq 1, LO Freq 2 and Crossover.
10.75 GHz
LO Freq 2 Enter number Enter if Ku-band dual LNB
application. LO Freq 2 > LO
Freq 1.
0.0
Crossover Enter number Enter if Ku-Band dual LNB
application. Determines if LO
Freq 1 or LO Freq 2 is used for
tuning.
0.0
LNB Power
(For more information,
see LNB Power
Settings, page 4-21
18-H For H polarization (18V). 18-H
13-V For V polarization (13V).
Off Use for external LNB power.
LNB power must be on if
DiSEqC is required.
H-NIT Initially applies the horizontal
polarization voltage, and then
follows the polarization based on
the NIT.
V-NIT Initially applies the vertical
polarization voltage, and then
follows the polarization based on
the NIT.
DiSEqC Enable
Disable
Enables or disables Digital
Satellite Equipment Control,
level 1.2. This must be enabled
to control the DiSEqC switch.
LNB Power must be on to use
this setting. Refer to
http://www.eutelsat.com/satellit
es/4_5_5.html for more
information.
Disable
Selection Options Description Default
