Cisco D9865 Satellite Receiver Software Version 2.20 Installation and Configuration Guide
OL-31085-01
Chapter 3 Front Panel Operation
About the Front Panel
To change a setting on a menu using the front panel:
Step 1 Use the  buttons to move to the setting you want to change. Press the Select button to select
the setting.
Step 2 For numeric options, you can:
• use the  buttons to change the value one digit at a time, or
• navigate to Keyboard using the  buttons to use an on-screen keyboard.
Step 3 To access the menus at the bottom of the screen (for example, Save), navigate to the appropriate selection
using the
 buttons and press Select. A help message is displayed at the bottom of the screen.
Step 4 Press Menu to move to the previous menu.
Front Panel LEDs
The functions of the LEDs are described in the table below:
Button Function
DISPLAY Enables the video display output.
When the video display is enabled, the channel number is
displayed on the front panel. When switched off, a “.” flashes.
MENU Enters Menu mode or returns to video.
Returns to previous menu.
SELECT Selects menus.
Enters or exits edit mode.

In Menu mode, used to navigate menus.

In Video mode, used for volume up/down.

In Video mode, used for channel up/down.
LED Function
MUTE On when sound is muted.
SIGNAL On when receiver is synchronized with the incoming digital signal and
authorized for the current channel.
Flashing when a signal has been found, but receiver is not authorized
for the current channel.
Off when no signal has been found. For more information about
troubleshooting your satellite receiver, see Troubleshooting, page 6-13
MENU On when on-screen menus are displayed.
