4-22
Cisco D9865 Satellite Receiver Software Version 2.20 Installation and Configuration Guide
OL-31085-01
Chapter 4 Setup and Monitoring via On-Screen Display
Setup Menu
Step 2 The table at the top displays the current configurations.
Step 3 The following table describes each of the options in User mode:
Step 4 Press the yellow button to switch between User and Installer modes. The Installer mode is for Installers
only.
Step 5 The following table describes each of the available options for the Installer mode:
Selection Options Description
Satellite Number 1 to 255 Number identifying the saved satellite location as
defined by the dish motor manufacturer.
User Action None No action is performed.
Goto Satellite Moves the dish to the selected pre-stored satellite
position. Satellite positions are stored in the dish
motor, if supported, not in the receiver.
