4-46
Cisco D9865 Satellite Receiver Software Version 2.20 Installation and Configuration Guide
OL-31085-01
Chapter 4 Setup and Monitoring via On-Screen Display
Setup Menu
The Network Address, Mask, and Gateway Address should be changed together, as a group. The
following table shows the most commonly used Subnet mask values to enter for a chosen IP address
mask, which will depend on the size of your network.
Step 3 Press the green button (Save) to save your changes.
Editing a Unicast IP Address
Step 1 In the Unicast IP Setup screen, scroll to the unicast IP you want to edit using the  buttons.
Step 2 Press OK. The Edit/Delete Unicast IP screen is displayed.
Step 3 Select Edit or press the blue button (Edit). The Add/Edit Unicast IP screen is displayed.
Step 4 Make the necessary changes.
Step 5 Select the green button (Save).
Deleting a Unicast IP Address
Step 1 In the Unicast IP Setup screen, scroll to the unicast IP you want to delete using the  buttons.
Step 2 Press OK. The Edit/Delete Unicast IP screen is displayed.
Step 3 Select Delete or press the red button (Delete). A message appears to confirm the deletion.
Step 4 Press OK.
Selection Options Description
Network Address 12 digits in length
(###.###.###.###)
Sets the IP Address for its participation in
a Network environment.
Mask 8 to 32 Sets the Subnet Mask for its participation
in a Network environment.
Gateway Address 12 digits in length
(###.###.###.###)
Sets the Network Gateway Address on the
Network, used to expose the receiver to a
WAN .
Mask Subnet Mask
8 255.0.0.0
16 255.255.0.0
24 255.255.255.0
