show rep topology
This example shows output from the show rep topology segment archive command:
Switch# show rep topology segment 1 archive
REP Segment 1
BridgeName PortName Edge Role
---------------- ---------- ---- ----
sw1_multseg_3750 Gi1/1/1 Pri Open
sw3_multseg_3400 Gi0/13 Open
sw3_multseg_3400 Gi0/14 Open
sw4_multseg_3400 Gi0/13 Open
sw4_multseg_3400 Gi0/14 Open
sw5_multseg_3400 Gi0/13 Open
sw5_multseg_3400 Gi0/14 Open
sw2_multseg_3750 Gi1/1/2 Alt
sw2_multseg_3750 Gi1/1/1 Open
sw1_multseg_3750 Gi1/1/2 Sec Open
Related Commands Command Description
rep segment Enables REP on an interface and assigns a segment ID. This command is also
used to configure a port as an edge port, a primary edge port, or a preferred
port.
