2-129
Cisco ME 3800X and ME 3600X Switch Command Reference
OL-28238-01
Chapter 2 Cisco ME 3800X and ME 3600X Switch Cisco IOS Commands
l2 vfi
l2 vfi
To create a virtual forwarding infrastructure (VFI) and to enter manual VFI configuration mode, use the
l2 vfi command in global configuration mode. A VFI is a logical switching entity used to implement
hierarchical virtual private LAN service (H-VPLS) over a multiprotocol label switching (MPLS)
backbone. All interfaces attached to the VFI can participate in the switching. To delete the VFI, use the
no form of this command.
l2 vfi vfi-name manual
no l2 vfi vfi-name
Syntax Description
Defaults No VFIs are created.
Command Modes Global configuration
Command History
Usage Guidelines Entering the l2 vfi vfi-name manual command enables the VFI configuration mode. These configuration
commands are available:
• default: sets the command to the default states.
• exit: exits VFI configuration mode and returns to global configuration mode.
• no: negates a command or set its defaults.
• vpn id vpn-number: specifies the virtual private network (VPN) ID of the VPLS configured by the
VFI. For more information, see the vpn id command.
When you enter a vpn id vpn-number, these additional VFI configuration commands are available:
• neighbor remote-peer-IP-address encapsulation mpls: configures the IP address of the remote
peer, which is to become a member of the VPLS configured by the VFI, and sets the MPLS
encapsulation type.
• shutdown: shuts down the VFI interface.
The switch supports only one connection per VFI, so you can configure only one neighbor in a VFI. To
complete the connection, you attach a VLAN or Ethernet interface to the VFI by using the xconnect
interface configuration command. The switch supports multiple Ethernet interfaces or a single VLAN in
a VFI. It does not support switching a VLAN and physical interfaces through the same VFI.
The switch supports a total of 26 VRFs and VPNs.
vfi-name Name assigned to the VFI.
manual Specifies VFI manual configuration mode.
Release Modification
12.2(52)EY This command was introduced.
