User Manual Synertia® RF Generator 105
The information contained in this manual is subject to change by Comet Yxlon without prior notice.
Parameter
No.
Parameter
Name
Example
Value
Unit
Type
Enum
Values
Comment /
Description
2
“External Process”
An external process feedback
(e.
g. from an analog input) is
used for process control. The
output power is controlled to
obtain the process control
voltage set by the process set
point (see parameter 1222
“Process set point”).
1206
Power set
point
0
(
?0.000 W)
mW
int (32 bit)
Set point for “Output
Forward”
or “Load Power” in mW,
depending on the control mode
(see parameter 1201).
1222
Process set
point
4000000
(
? 4000.000
V)
mV
Process set point for “External
Process” in mV; value range from
0 to 20000000
Settings
" CEX
1102
Frequency
set point
13560000
(
?13560.000
kHz)
Hz
int (32 bit)
Output RF frequency in Hz; this
feature is only available in units
with selectable RF output
frequency.
Settings
" Pulsing
1301
Pulse mode
int (32 bit)
The pulse feature can be
turned
on and off and the pulse mode
can be selected.
0
“Off”
The pulse feature is turned off.
1
“Pulse mode external”
The pulse is generated by an
external source.
2
“Pulse mode internal 1”
The pulse is generated
internally.
11
“Pulse mode external inverted”
The pulse is generated by an
inverted external source.
