CTS FOS-3126-PLUS SERIES - Page 33

33
[dest_port]
“any”: Specify “any” to filter frames
from any destination ports.
“0-65535”: Specify a destination port
between 0 and 65535.
“0-65535/0-65535”: Specify a range of
destination ports. For example,
“1000/2000” means that port numbers
from 1000 to 2000 are specified. The
starting destination port number
is1000; whereas, the ending
destination port number is 2000.
[source_ip]
This is sender IP filtering function.
Specify “any” to filter frames from any
sender IP addresses. Or, specify a
host IP address (x.x.x.x).
[ip_mask]
Define source IP mask.
“any”: Specify “any” to mean any IP
mask.
“255.255.0.0”: Specify a specific IP
mask.
[dest_ip]
This is destination IP filtering function.
“any”: Specify “any” to filter frames to
any target IP addresses.
“x.x.x.x”: Specify either a host IP
address.
[ip_mask]
Define destination IP mask.
“any”: Specify “any” to mean any IP
mask.
“255.255.0.0”: Specify a specific IP
mask.
[ip_ttl]
Specify IP TTL bit.
“any”: Specify “any” to denote the
value which is either zero or not zero.
“0”: Specify “0” to indicate that the TTL
filed in IPv4 header is 0.
“1”: If the value in TTL field is not 0,
use “1” to indicate that.
