CTS FOS-3126-PLUS SERIES User Manual

37
Switch(config-acl-RULE)#
ingress-port [any | policy1-
8 | port]
[any | policy1-8 |
port 1~26]
Specify one option for ingress port
command.
“any”: Specify “any” to mean any
ports are ingress ports.
“policy1-8”: Specify a policy that
applies to ingress port command. To
make this command work properly, you
must configure “Switch(config-if-xx-
xx)# acl policy [1-8]” command.
“port”: Specify a port number (1~26)
as an ingress port.
Switch(config-acl-RULE)#
tag-priority [0-7]
[0-7]
Configure the tag priority for this ACL
rule. The allowable tag priority value is
between 0 and 7.
Switch(config-acl-RULE)#
vid [any |1-4094]
[any |1-4094]
Configure the VLAN ID filter function.
“any”: Specify “any” to mean any
VLAN ID.
“1-4094”: Specify an existing VLAN
ID.
Switch(config)# acl rate-
limiter [1-14] [rate_pps]
[1-14]
Specify the rate limiter ID that you
would like to assign a rate value to it.
[rate_pps]
Assign the rate to this specified rate-
limiter ID.
The allowable rates are listed below.
0:1pps | 1:2pps | 2:4pps | 3:8pps |
4:16pps | 5:32pps | 6:64pps |
7:128pps | 8:256pps | 9:512pps |
10:1kpps | 11:2kpps | 12:4kpps |
13:8kpps | 14:16kpps | 15:32kpps |
16:64kpps | 17:128kpps | 18:256kpps |
19:512kpps | 20:1024kpps
Specify “0” to denote 1pps and so on.
NOTE: To view the rate list in CLI,
press “?” key after the command. For
example, “Switch(config)# acl rate-
limiter 2?”
No command
Switch(config-acl-RULE)#
no action
Permit the action.
Switch(config-acl-RULE)#
no action port-copy
Disable port-copy function.
Switch(config-acl-RULE)#
no action rate-limiter-id
Disable rate-limiter function.
Switch(config-acl-RULE)#
no action shutdown
Activate the interface.
