DES-3000 Series Layer 2 Switch CLI Reference Manual

show dscp_mapping

Purpose To display current DSCP mapping.

Syntax

show dscp_mapping { dscp_value <value 0-63> }

Description Use this to display the CoS priority level currently mapped for DSCP

levels.

Parameters dscp_value <value 0-63> - Specify a DSCP value to view the current

value mapped to it in the Switch.

Restrictions Only administrator-level users can issue this command.

To display current CoS mapping for DSCP:

DES-3026:4#show dscp_mapping dscp_value 13

Command: show dscp_mapping dscp_value 13

DSCP Class

---------------------

13 0

DES-3026:4#
