DES-3000 Series Layer 2 Switch CLI Reference Manual
config 802.1p user_priority
Purpose Used to map the 802.1p user priority of an incoming packet to one of the four
hardware classes of service available on the Switch.
Syntax
config 802.1p user_priority <priority 0-7> <class_id 0-3>
Description
The config 802.1p user_priority command is used to configure the way the Switch
will map an incoming packet, based on its 802.1p user priority tag, to one of the four
hardware priority classes of service available on the Switch. The Switch’s default is to
map the incoming 802.1p priority values to the four hardware classes of service
according to the following chart:
802.1p Switch Priority
Value Queue
--------- ------------------
0 1
1 0
2 0
3 1
4 2
5 2
6 3
7 3
Parameters
<priority 0-7> − Specifies to which of the eight 802.1p priority values (0 through 7) to
map to one of the Switch’s hardware priority classes of service (<class_id>, 0 through
3).
<class_id 0-3> − Specifies to which of the Switch’s hardware priority classes of
service the 802.1p priority value (specified above) will be mapped.
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure 802.1 user priority on the Switch:
DES-3026:4# config 802.1p user_priority 1 3
Command: config 802.1p user_priority 1 3
Success.
DES-3026:4#
102
