DES-3000 Series Layer 2 Switch CLI Reference Manual
config cos mac_mapping destination_addr
Purpose Used to map the destination MAC address of an incoming packet to one of the
hardware queues available on the Switch.
Syntax
config cos mac_mapping destination_addr <macaddr> [class <class_id 0-3>]
Description Use this command to map a static destination MAC address to one of the four
hardware queues on the Switch. The static MAC address must exist in the Switch
forwarding database in order to use this command. See the command create fdb
<vlan_name 32> <macaddr> port <port> for an example of how to create a static
entry in the FDB.
Parameters <macaddr> - Specify the static destination MAC address to be mapped to a harware
queue.
class <class_id 0-3> – Specify the hardware queue to which the MAC address is
mapped.
Restrictions Only administrator-level users can issue this command.
Example usage:
To map a static MAC address to hardware queue 3:
DES-3026:4#config cos mac_mapping destination_addr 01-00-D6-E4-FF-05 class 3
Command: config cos mac_mapping destination_addr 01-00-D6-E4-FF-05 class 3
Success!
DES-3026:4#
show cos mac_mapping
Purpose Used to display MAC address CoS mapping configuration.
Syntax
show cos mac_mapping { destination_addr < macaddr > }
Description Use this command to view a single entry or all entries configured for CoS MAC address
mapping.
Parameters destination_addr < macaddr > - Specify a static MAC address entry to view the current
CoS mapping configuration. If no entry specified, all MAC mapping entries are listed.
Restrictions None.
110
