DES-3000 Series Layer 2 Switch CLI Reference Manual

show log_save_timing

Purpose Used to display the method currently used for automatic saving of log to Syslog host.

Syntax

show_save_timing

Description

The show log save timeing command will display the current configuration of saving

Switch logs to designated hosts.

Parameters None.

Restrictions Only administrator-level users can issue this command.

Example usage:

To configure log timing:

DES-3026:4#show log_save_timing

Command: show log_save_timing

Saving log method : on_demand

DES-3026:4#
