DES-3000 Series Layer 2 Switch CLI Reference Manual

show mac_notification

Used to display the Switch’s MAC address table notification global

settings

Syntax

show mac_notification

Description This command is used to display the Switch’s MAC address table

notification global settings.

Parameters None.

Restrictions None.

Purpose

Example usage:

To view the Switch’s MAC address table notification global settings:

State : Enabled

DES-3026:4#show mac_notification

Command: show mac_notification

Global Mac Notification Settings

Interval : 1

History Size : 1

DES-3026:4#

140
