D-Link DWS-3000 Series

DiffServ Class Commands 233
5 Quality of Service (QoS) Commands
Format diffserv
Mode Global Config
no diffserv
This command sets the DiffServ operational mode to inactive. While disabled, the DiffServ
configuration is retained and can be changed, but it is not activated. When enabled, Diffserv
services are activated.
Format
no diffserv
Mode Global Config
DiffServ Class Commands
Use the DiffServ class commands to define traffic classification. To classify traffic, you
specify Behavior Aggregate (BA), based on DSCP and Multi-Field (MF) classes of traffic
(name, match criteria)
This set of commands consists of class creation/deletion and matching, with the class match
commands specifying Layer 3, Layer 2, and general match criteria. The class match criteria
are also known as class rules, with a class definition consisting of one or more rules to identify
the traffic that belongs to the class.
NOTE: Once you create a class match criterion for a class, you cannot change or
delete the criterion. To change or delete a class match criterion, you must
delete and re-create the entire class.
The CLI command root is
class-map.
class-map
This command defines a DiffServ class of type match-all. When used without any match
condition, this command enters the class-map mode. The
<class-map-name> is a case
sensitive alphanumeric string from 1 to 31 characters uniquely identifying an existing DiffServ
class.
NOTE: The class-map-name 'default' is reserved and must not be used.
The class type of
match-all indicates all of the individual match conditions must be true for
a packet to be considered a member of the class.
NOTE: The CLI mode is changed to Class-Map Config when this command is suc-
cessfully executed.
Format
class-map match-all <class-map-name>
Mode Global Config
no class-map
This command eliminates an existing DiffServ class. The <class-map-name> is the name of
an existing DiffServ class (The class name 'default' is reserved and is not allowed here). This
