Setting Up the Scanner
Product Reference Guide 7
Figure 2. Connection to the Host
USB
Keyboard Wedge
RS-232
NOTE
Specific cables are required for connection to different hosts. The connections illus-
trated in Figure 2 are examples only. Actual connecto
rs may vary from those illus-
trated, but the steps to connect the scan
ner remain the same.
