2. Enter the appropriate information in the form as described below:
Field Name
Action/Definition
Search for CBX
BM100
at Device Startup
Select the check box to automatically search for a BM100 storage module
when the scanner is powered on.
Data Tx
Select the check box to enabled Data Tx. If selected, the Aux Serial Port
channel is used by the scanner to transmit data and/or messages.
Heartbeat
Select Disable, Enable Unconditioned, or Enable Conditioned from the
drop-down list. This parameter is available when the Data TX parameter is
checked. It enables/disables the transmission of the Heartbeat message
signaling that the device is still active.
 Disable: The Heartbeat message is not transmitted
 Enable Unconditioned: The Heartbeat message is always transmitted,
even if communication is still active
 Enable Conditioned: The Heartbeat message is transmitted only when
there is no communication
Heartbeat Settings
Heartbeat Timeout
Enter a time value in seconds to define the amount of time between two
message transmissions. If the input timeout expires and no transmission has
occurred, the Heartbeat message will be transmitted.
Heartbeat Message
(max. 32 chars)
Click to activate the Text Entry Tool and create Heartbeat Header text to
signal the beginning of the heartbeat message. Characters from NUL (00H) to
~ (7EH) can be used. Click Submit to save your text to the origin window text
field, or click Cancel to return to origin window without transferring text.
The Heartbeat Message (header) string must be different from the Heartbeat
Terminator string.
Heartbeat Terminator
(max. 32 chars)
Click to activate the Text Entry Tool and create Heartbeat Terminator
text to signal the end of the heartbeat message. Characters from NUL (00H)
to ~ (7EH) can be used. Click Submit to save your text to the origin window
text field, or click Cancel to return to origin window without transferring text.
The Heartbeat Terminator string must be different from the Heartbeat
Message (header) string.
Line Settings
Baud Rate
Select a value from 1200 to 115200 from the drop-down list. Baud Rate is the
transmission speed in a communication line.
Parity
Select None, Odd, or Even from the drop-down list. Parity is a parameter
indicating the presence of a control bit in the communication protocol frame.
Data Bits
Select 7 or 8 from the drop-down list. Data Bits is a parameter indicating the
number of bits composing the data packet of the communication protocol
frame.
Stop Bits
Select 1 or 2 from the drop-down list. Stop Bits is a parameter indicating the
number of stop bits in the data packet of the communication protocol frame.
3. When you have finished making changes, click Update All to save all pending changes,
click Reset All to revert to all previously saved values, and click Reset Page to revert to
previous saved values on the current page.
