Code
Direction
Identifier
Enable
Select the check box to enable. If enabled, it allows you to define the forward and reverse
strings indicating the scanning direction with respect to the code direction.
Click to activate the Text Entry Tool and create a Forward Direction String in the text
field provided. A Forward Direction String can be included in the output message to
indicate that the current code has been scanned in the forward direction (scanning from left
to right).
This string ("+" is the default value) can be customized by the user including up to 32
characters.
Click Submit to save your text to the origin window text field, or click Cancel to return to
origin window without transferring text.
Click to activate the Text Entry Tool and create a Reverse Direction String in the text
field provided. A Reverse Direction String can be included in the output message to
indicate that the current code has been scanned in the reverse direction (scanning from
right to left).
The string ("-" is the default value) can be customized by the user including up to 32
characters.
Click Submit to save your text to the origin window text field, or click Cancel to return to
origin window without transferring text.
Click to activate the Text Entry Tool and create an Unknown Direction String in the
text field. An Unknown Direction String can be included in the output message when it is
not possible to determine the scanning direction of a code.
The string ("?" is the default value) can be customized by the user including up to 32
characters.
Click Submit to save your text to the origin window text field, or click Cancel to return to
origin window without transferring text.
Code Field
Length
Setting
Select Variable or Fixed from the drop-down list. If Variable is chosen, all possible code
field lengths (in number of characters/digits) allowed for the code selected are accepted. If
Fixed is chosen, only the length defined by the Code Field Length parameter is accepted.
This parameter is only available when Fixed is selected as the Code Field Length
Setting. Enter length of the code field to be transmitted (in number of characters/digits) in
the field provided.
This parameter is only available when Fixed is selected as the Code Field Length
Setting. Select Left or Right from the drop-down list to define the position of the Fill
Character within the code.
