DS8110 REFERENCE MANUAL
138
4
Field Name
Action/Definition
Format Type: Advanced
Select a
Message
Number to
Modify
Select a numbered message you wish to modify from the drop-down list.
Advanced Format: Message Definition n
Message
Destination
Select the check box for each port or socket that should receive the message.
Message
Destination
Bitmap
Indicates the destination of the message.
Message
Alignment
Select None, Left, or Right from the drop-down list.
Align Length
Enter the number of characters by which to extend the message when Left or Right is
selected from the Message Alignment drop-down box.
