E-GENIUS
141
4
Field Name
Action/Definition
Move up
Click to move the selected message item up one level in the list.
Move down
Click to move the selected message item down one level in the list.
Remove
Click to remove the selected message item.
Item n Definition
Item Type
Select Text String, Code Related Item, or Package Related Item from the drop-down
list. Each selection reveals a unique set of options.
String Field
Click to activate the Text Entry Tool and create a text string message. This option
is available when Item Type > Text String has been selected.
Click Submit to save your text to the origin window text field, or click Cancel to return
to origin window without transferring text.
Code Related
Items
Select a code related item from those available in the drop-down list. This option is
available when Item Type > Code Related Item has been selected. The Code Related
Items can be associated to a specific programmed code or group label depending on
the Code Combination selection.
Selections Include:
 Barcode: Barcode data
 Barcode Length: Number of characters in code
 Read Bitmap: 32-bit mask indicating which scanner in the network has read the
code (when character <1> is present in the related position)
 Total Read Count: Indicates how many times the code has been read by all
scanners present in the network during the same reading phase
 Read Count (by device): Indicates the number of times the code has been read
by one specific scanner present in the network during the reading phase
(selectable among those present)
 X Position: X coordinate for the code that was read
 Y Position: Y coordinate for the code that was read
 Z Position: Z coordinate for the code that was read
 Code Identifier: Indicates type of code that was read
 Code Direction: Indicates if the code has been read either from either the start
character or the stop character
 Code Distance: Indicates the distance to the code that was read
 Decode Mode: Indicates if the code has been read using Linear or
Reconstruction (ACR) reading mode
 Decode Scans Number: Indicates the minimum number of decoded scans
