DS8110 REFERENCE MANUAL
142
4
Field Name
Action/Definition
referred to the single characters in a code when the device is reading in
Reconstruction mode. This Item can be used as Code Quality Index
 Average Code Position: Average position of the code in the scan line (Average
of Minimum and Maximum Code Position)
 Minimum Code Position: Minimum position of the code in the scan line (closest
to the left side/connector side of the scanner)
 Maximum Code Position: Maximum position of the code in the scan line
(farthest from the left side/connector side of the scanner)
 Ink Spread: Indicates the calculated Ink Spread value
 Encoder Value: Indicates the encoder/tachometer pulse value from trigger to the
code being read
 Laser Number: If more than one laser is present in the working device, this item
indicates the laser used to read the code
 Reading Persistence: Indicates how many times the laser beam has crossed
the complete code during the reading phase
Package
Related Item
Select a package related item from those available in the drop-down list. This option
is available when Item Type > Package Related Item has been selected.
Selections Include:
 Package Sequence Number: Indicates the sequential number assigned to the
package.
 Total Read Bitmap: Indicates the complete reading mask related to all codes
read during the reading phase
 Failure Bitmap: 32-bit mask indicating which devices in the network are in fault
(when character <1> is present in the related position)
 Total Read Count: Indicates the sum of all Code-related Total Reading Counts of
each code read during the reading phase
 Read Count (by device): Indicates the number of codes read during the reading
phase by the device
 Minimum Code Distance: Indicates the distance of the code closest to the
device read during the reading phase
 Maximum Code Distance: Indicates the distance of the code most distant from
the scanner that has been read during the reading phase
 Decode Mode (Master): Indicates the programmed Reading Mode, either Linear
or Reconstruction
 Number of Rejected Codes: Indicates the number of codes rejected during the
internal analysis (unexpected code, multiple read, discarded by the programmed
logical rule)
 Package Length: Indicates the approximate length of the package
