DS8110 REFERENCE MANUAL

Field Name

Action/Definition

Maximum

Length

Displays the maximum barcode character length for that row's symbology.

Barcode n

NOTE: Input fields will vary depending on the selected symbology.

Enable

Select the Enable check box to activate the selected barcode. Deselect the Enable

check box to disable the selected barcode. When the check box has been selected,

configuration and code type options are displayed.

Code

Symbology

Select a barcode symbology from those available in the Code Symbology drop-down

list.

EAN Add On

Select No Add On, 2 digit Add On, or 5 digit Add On from the EAN Add On drop-

down list. Selecting 2 digit Add On or 5 digit Add On adds that many digits as a

supplement to the barcode. EAN is the acronym for International Article Number,

previously known as European Article Number.

Minimum

Label Length

Enter the minimum character length for the selected barcode.

Maximum

Label Length

Enter the maximum character length for the selected barcode.

Match String

Rule

Select Match or Do Not Match from the drop-down list. This parameter defines the

matching rule, according to which a code can be transmitted.

 Match: All codes matching the Pattern Match String will be transmitted

 Do Not Match: All codes not matching the Pattern Match String will be

transmitted

Pattern Match

String (max.

200 chars)

Click to activate the Text Entry Tool and create a pattern match string. A code can

also be identified by its content. A pattern matching string is programmable for each

code and if the read codes do not match the defined string, a No Read Event will be

returned.

It is possible to define the matching string by inserting:

 all printable characters

 non printable ASCII characters available in the list which appears by right-

clicking on the parameter edit box

 * = defining any string consisting of an undefined number of characters (it may

be empty)

 ? = identifying any character to be found in the position indicated within the

string

If your application requires inserting ?, * and NUL as characters, it is necessary to use

the following syntax:

 ? character = <NUL>?

 * character = <NUL>*

 NUL character = <NUL>00

 other extended ASCII characters = <NUL>xy, where xy identifies the character

hex value
