INTERNAL NETWORK CONFIGURATIONS
PRODUCT REFERENCE GUIDE
157
3. Now save them, overwriting the cloned application job
1
.
Figure 101 - Saving Synchronized Phase Mode Configuration to Slave
Repeat this procedure for each Slave device until the entire network is configured.
See "
ID-NET Synchronized Network" on page 103 for an example.
1. An application job with the same name as the Master’s has been cloned to the Slaves. Each
Slave can have its own Image Settings parameters saved in its own copy of the application job.
Common parameters managed by the Master such as Operating Mode cannot be modified in
the Slave jobs and are shown in dark gray.
