BM150 DISPLAY MODULE CONFIGURATION AND MESSAGES
PRODUCT REFERENCE GUIDE
173
Network State (Master only)
M = Master diagnostic condition; S = Slave diagnostic condition:
* = scanner OK
- =s
canner not detected at startup
? =scanner detected at startup but not responding to diagnostic polling
! = scanner diagnostic error
Standard Reading Results
A = reading result – Good Read, Partial Read, Multiple Read
X = code content
Y = number of codes read
Reading Mask Only (Master Only)
X = code content (or "No Read" or "Multiple Read")
Y = Good Read, No Read, Multiple Read and Partial Read
counters on the last 100 codes
read (%)
S = Reading Mask for Stand Alone or Master plus Slave readers 1 - 15
(0 = No Read, 1 = Good Read, M = Multiple Read)
T = Reading Mask for Slave readers 16 - 31
(0 = No Read, 1 = Good Read, M = Multiple Read)
Reading Mask/Device State (Master Only)
X = Recognized code label data (or "No Read" or "Multiple Read")
Y = Phase Counter (range: 0000000 to 9999999)
Z = Good Read or Multiple Read counters (%)
