Datalogic Matrix 220 - Page 76

47
[1.85]
63
[2.48]
37.6
[1.48]
58
[2.26]
20.5
[0.81]
n°2
4 mm
8
[0.32]
28.1
[1.11]
43
[1.68]
x
Ø3
[Ø0.12]
mm
[inch]
optical axis
optical axis
INSTALLATION
58 MATRIX 220
Figure 34 - Overall Dimensions with Accessory Cover (ESD or YAG); Connector at 90°
