Datalogic Matrix 220 - Page 75

47
[1.85]
58
[2.27]
28.1
[1.11]
n°2
4 mm
37.6
[1.48]
20.5
[0.81]
78
[3.07]
43
[1.68]
43
[1.68]
x
Ø3
[Ø0.12]
mm
[inch]
optical axis
optical axis
MECHANICAL DIMENSIONS
PRODUCT REFERENCE GUIDE 57
Figure 33 - Overall Dimensions with Accessory Cover (ESD or YAG); Connector at 0°
