Reading Features
100
Matrix 300N
2 MP Software Adjustable Liquid Lens Models 9 mm (45°)
1D Codes
Horizontal FoV
Reading Distance
Figure 79 - 9 mm Global FOV Diagram
2D Codes
Horizontal FoV
Reading Distance
Figure 80 - 9 mm Global FOV Diagram
NOTE
The Polarized and Diffused embedded lighting systems are optimized to work at dis-
tances up to 350 mm. For longer reading distances, Datalogic recommends the use of
Matrix 300N 2MP Standard models or external illumination.
