Optical Features
Image Sensor CMOS sensor with Global Shutter
Image Format
4xx-0xx models 7xx-0xx models
1.3 M pixels SXGA
(12
80X1024) pixels
2.0 M pixels UXGA
(1600X1200) pixels
Frame Rate 45 frames/sec.
Pitch  35°
Tilt 0° - 360°
LED Safety according to EN 62471
Lenses
Focal Length
Manual Adjustable Focus
4x1-0xx models = 6 mm
4x3-0xx models = 9 mm
4x4-0xx models = 12 mm
4x5-0xx models = 16 mm
Software Adjustable Focus
4x2-0xx models = 9 mm
7x2-0xx models = 9 mm
7x6-0xx models = 16 mm
Lighting System Internal Illuminator
Aiming System Laser Pointers
Technical Features
214 Matrix 300N
Optical Features

Datalogic Matrix 300N Specifications

General

Type	Barcode module bar barcode readers
Sensor type	CMOS
Scanner type	1D/2D
Yaw reading angle	0 - 24 °
Optical sensor resolution	1024 pixels
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Input voltage	10 - 30 V
Power consumption (typical)	5 W
Connectivity technology	Wired
Certification	AIM DPM, ISO/IEC 15415, ISO/IEC 15416, ISO/IEC 16022, ISO/IEC 18004, AS9132A
Product color	Blue, Metallic
Housing material	Aluminium, Plastic
International Protection (IP) code	IP67
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	54 mm
Width	75 mm
Height	62 mm
Weight	238 g
