Datalogic Matrix 300N User Manual

Software Configuration
158 Matrix 300N
Master Configuration
First start with the desired device to assign as ID-NET Master (current default
setting is Slave). Click on Setup Internal Network Configuration from the Task
area.
You will be advised that the device role will be changed to Master.
Click OK. The Net Autoset feature automatically starts to find Slave devices
connected to the ID-NET network of the Master.
When finished, all the Slaves should have been correctly recognized. If not, verify
all device connections and power and then repeat the operation by clicking on
the Start Net Autoset button.

Datalogic Matrix 300N Specifications

General

Type	Barcode module bar barcode readers
Sensor type	CMOS
Scanner type	1D/2D
Yaw reading angle	0 - 24 °
Optical sensor resolution	1024 pixels
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Input voltage	10 - 30 V
Power consumption (typical)	5 W
Connectivity technology	Wired
Certification	AIM DPM, ISO/IEC 15415, ISO/IEC 15416, ISO/IEC 16022, ISO/IEC 18004, AS9132A
Product color	Blue, Metallic
Housing material	Aluminium, Plastic
International Protection (IP) code	IP67
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	54 mm
Width	75 mm
Height	62 mm
Weight	238 g
