Datalogic Matrix 300N User Manual

Product Reference Guide 135
Chapter 7
Software Configuration
Software configuration of your Matrix 300N for static reading or simple code
reading applications can be accomplished by the Rapid Configuration procedure
using the X-PRESS HMI (which requires no external configuration program). This
procedure is described in Chapter 1, Steps 3-4.
For the majority of applications however you will use DL.CODE, connecting to the
reader through the on-board Ethernet interface. See Chapter 1, Steps 5-6.
DL.CODE System Requirements
CAUTION
To install and run DL.CODE you should have a Laptop or PC that meets or
exceeds the following:
• 2.00 GHz or faster microprocessor
• Windows: 7, 8, or 10
•1 GB RAM
• 2 GB hard disk for 64-bit machines; 1 G
B hard disk for 32-bit machines
•100 Base-T Ethernet
• One 19" or larger monitor (optimized for
1280x1024 resolution)
CAUTION
DL.CODE does not currently support Windows Embedded (often used in industrial PCs
and/or PLCs).
The Windows XP operating system is no longer supported by DL.CODE.

Datalogic Matrix 300N Specifications

General

Type	Barcode module bar barcode readers
Sensor type	CMOS
Scanner type	1D/2D
Yaw reading angle	0 - 24 °
Optical sensor resolution	1024 pixels
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Input voltage	10 - 30 V
Power consumption (typical)	5 W
Connectivity technology	Wired
Certification	AIM DPM, ISO/IEC 15415, ISO/IEC 15416, ISO/IEC 16022, ISO/IEC 18004, AS9132A
Product color	Blue, Metallic
Housing material	Aluminium, Plastic
International Protection (IP) code	IP67
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Depth	54 mm
Width	75 mm
Height	62 mm
Weight	238 g
