Rapid Configuration
2
Matrix 300N
CBX100/CBX500 Pinout for Matrix 300N
The table below gives the pinout of the CBX100/CBX500 terminal block
connectors. Use this pinout when the Matrix 300N reader is connected by means
of the CBX100/CBX500:
CBX100/500 Terminal Block Connectors
Input Power Outputs
Vdc Power Supply Input Voltage + +V Power Source - Outputs
GND Power Supply Input Voltage - -V Power Reference - Outputs
Earth Protection Earth Ground O1+ Output 1+
O1- Output 1-
Inputs
02+ Output 2+
+V Power Source - External Trigger O2- Output 2-
I1A External Trigger A (polarity insensitive)
O3A Output 3 (CBX500 only)
I1B External Trigger B
(polarity insensitive)
-V Power Reference - External Trigger
Auxiliary Interface
+V Power Source - Inputs TX
I1A Input 2 A
(polarity insensitive) RX
I2B Input 2 B
(polarity insensitive) SGND
-V Power Referenc
e - Inputs
ID-NET™
Shield
REF Network Reference
Shield Network Cable Shield ID+ ID-NET network +
ID- ID-NET network -
Main Interface
RS232 RS422 Full-Duplex
TX TX+
- TX-
RX
a
a. Do not leave floating, see RS232 Interface for connection details
RX+
- *RX-
SGND SGND
CAUTION
Do not connect GND, SGND and REF to different (external) ground references. GND,
SGND and REF are internally connected through filtering circuitry, which can be per-
manently damaged if subjected to voltage drops over 0.8 Vdc.
