Reading Features
108
Matrix 300N
Matrix 300N 4x1-0xx (6 mm manual lens)
Code 128 0.50 mm (20 mils)
Reading Distance
Horizontal Reading Width
mm
in 6 8 10 12 14 16
-8
-6
-4
0
2
4
6
8
-2
Conditions
Hardware Settings
Code Symbology Code 128
Code Resolution 0.50 mm (20 mils)
Tilt Angle 0°
Skew Angle 15°
Focusing Distance (mm) 270 290
Software Parameters
Internal Lighting Very High Power Strobed
411-0xx Wide Red
Exposure Time (μs) 330 330
Gain 23 25
