Reading Features
116 Matrix 300N
Matrix 300N 4x3-0xx (9 mm manual lens)
Data Matrix 0.19 mm (7.5 mils)
Reading Distance
Horizontal Reading Width
mm
in 4 4.5 5 5.5 6 6.5
-2.5
-2
-1.5
-1
-.5
0
.5
1
1.5
2
2.5
Conditions
Hardware Settings
Code Symbology Data Matrix ECC 200
Code Resolution 0.19 mm (7.5 mils)
Tilt Angle 45°
Skew Angle 15°
Focusing Distance (mm) 135
Software Parameters
Internal Lighting Very High Power Strobed
423-0xx Medium Red
Exposure Time (μs) 130
Gain 5
