BM150 Display Module Configuration and Messages
Product Reference Guide 181
To enter the Main Menu press the Up and Down buttons simultaneously.
The menu structure is shown below.
Main Menu:
1. [Exit] (exi
ts HMI Interface menu)
2. Test Mode
(performs Test mode)
3. Fo
cus/Locate (performs Focus function: turns on LED pointers)
4. Calibra
tion (performs Setup function)
5. Code Se
tting (performs Learn function)
6. Match Code
Tra (Training: allows to read a code and store it as the Match
code)
7. Vi
ew Menu (Master Only):
[Exit] (r
eturns to Main menu)
Standard (displays the Standard Reading Results screen during run
mode)
Reading Mask (displays the Reading Mask or Reading Mask/Device State
screen during run mode) depends o
n the selection in DL.CODE (see
Configuration Through DL.CODE).
Network State (di
splays the Network State screen during run mode)
8. Extended Menu:
[Exit] (r
eturns to Main menu)
Backup
(performs Backup - uninterruptible)
Restore (per
forms Restore - uninterruptible)
Erase (erases the backup configuration in external memory -
uninterruptible)
To move through the list press and release the Up or
Down key.
To select an item or enter a submenu, press and release the Enter ke
y. After
executing an HMI function the display shows a result message and then
automatically exits from the menu structure.
To exit a menu manually, press and release the Enter
key at the [Exit] item or
press the Up and Down buttons simultaneously.
To exit from a running HMI function, press the Up and Do
wn buttons
simultaneously. These functions will also exit upon their configured timeout.
NOTE
When the HMI Interface is entered from either the Local Device (reader) or Remote
Device (BM150), the key(s) on the other device are disabled.
